Operator using Crown WJ walkie pallet truck in warehouse

Contents

4
General Information
You Must Be Trained8
Intended Use of the Truck8
Symbols Overview10
Text Marking Overview11
Safety Messages12
Know the Hazards14
Your Truck
Your Pallet Truck20
Truck Overview22
Data Capacity Plate26

You Must Be Trained

8
WARNING
STOP
You Must Be Trained and Certified

Only properly trained operators are permitted to operate a powered industrial truck.

Your employer must train you and certify that you are qualified to operate this powered industrial truck. (OSHA §1910.178)

You could be killed or seriously injured if you are not adequately trained for lift truck operation!

Do not operate this truck until you have been trained and certified by your employer.

Intended Use of the Truck

Your walkie pallet truck is designed to lift and transport loads. Your operating temperature range is 0°C to 40°C (32°F to 104°F).

The truck and battery, can be transported in temperatures down to -15°C (5°F).

The truck is not authorized for use on public roads.

Truck Overview

22
Walkie pallet truck with numbered callouts
1
2
3
4
5
6
7
8

Pallet Truck

  • 1
    Control Handle
  • 2
    Control Arm
  • 3
    Battery
  • 4
    Emergency Disconnect
  • 5
    Cable Storage option
  • 6
    Forks
  • 7
    Power Unit
  • 8
    Load Wheels
